M12 FUEL™ sub compact hackzall™



Brushless POWERSTATE™ motor for up to 6x longer motor life and up to 70% faster cutting in certain applications

REDLINK PLUS™ intelligence system delivers an advanced digital overload protection for tool and battery and uniquely enhances the tool performance under load

REDLITHIUM™ battery pack provides superior pack construction, electronics and fade-free performance to deliver more run time and more work over pack life

Individual battery cell monitoring optimises tool run time and ensures long term pack durability

Patented FIXTEC™ clamp for fast and easy keyless blade change

Counter balance mechanism lowers vibration to 6.5 m/s² allowing the operator to work safely for longer periods of time reducing fatigue

Sealed gearbox prevents water and debris entering the housing

LED light illuminates the cutline in low light conditions

Compact and light weight allows users to complete applications in restricted areas

Flexible battery system: works with all MILWAUKEE® M12™ batteries

Select Model Variant

M12 CHZ-602X

  • M12 CHZ-602X
  • M12 CHZ-0

Where to buy

Find a store

Range Spec

Product Specifications M12 CHZ-602X
M12 CHZ-602X
M12 CHZ-0
M12 CHZ-0
Article Number 49334519084933446960
Battery pack capacity (Ah) 6.0No batteries supplied
Battery type Li-ionLi-ion
Kit included 2 x M12 B6 Battery packs, C12 C Charger, HD Box
No load stroke rate (spm) 0 - 30000 - 3000
No. of batteries supplied 20
Standard equipment 1 x Sawzall™ blade1 x Sawzall™ blade
Stroke length (mm) 15.915.9
Supplied in HD BoxNo kitbox or bag supplied
Vibration cutting [m|s²] 5.75.7
Vibration cutting boards uncertainty [m|s²] 1.51.5
Vibration cutting in boards [m|s²] 5.75.7
Vibration cutting uncertainty [m|s²] 1.51.5
Vibration cutting wooden beam [m|s²] 6.526.52
Vibration cutting wooden beam uncertainty [m|s²] 1.51.5
Voltage (V) 1212
Weight with battery pack (EPTA) (kg) 1.6 (M12 B6)1.6 (M12 B4)
Sound power level (Lwa)(dB(A)) 93.993.9
Sound power level uncertainty [dB[A]] 33
Sound pressure level (Lpa)(dB(A)) 82.982.9
Sound pressure level uncertainty [dB[A]] 33
Manuals & Spare Parts View View
Product Data A4 DownloadDownload
Product Data A4 - Landscape DownloadDownload
Product Data A5 DownloadDownload
Fact Tag 14.9 x 6.9cm DownloadDownload
Fact Tag 15.5 x 8.5cm DownloadDownload
